PI polyimide gold finger film

FOB Reference Price:Get Latest Price
$21.95 - $34.50 / Kilograms | 10 Kilogram/Kilograms chemical resistant tape/yellow reflective tape/chemical resistan (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Material:
Polyimide
Use:
Masking
Adhesive Side:
Single Sided
Adhesive:
Silicone
Adhesive Type:
Pressure Sensitive
Feature:
Heat-Resistant
Design Printing:
No Printing
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Runsea or OEM
Model Number:
RH100
Application:
Polyimide pcb material thermal Resistance Film/Insulation Film
Applications:
flexible printed circuits and as insulating materials
Name:
chemical resistant tape/yellow reflective tape/chemical resistant tape
Sample:
free sample
Temperature:
-452F(-269°C) +500F(+260°C)
Features:
excellent physical, chemical,electrical,
Manufacture:
Yes
Available:
In rolls, in strips,any size
Properties:
atomic radiation resistant,solvent resistant,
Thickness:
0.025mm-0.25mm
Supply Ability
Supply Ability:
56000 Kilogram/Kilograms per Day chemical resistant tape/yellow reflective tape/chemical resistan
Packaging & Delivery
Packaging Details
by kraft carton with PE bags.
Port
Shenzhen or HK
Lead Time :
3-6 days after confirming PO and deposit

PI polyimide gold finger film



Polymide Film

Polyimide film is an electrical insulation material with outstanding thermal, mechanical, chemical and electrical properties.

Polyimide film has been used successfully in field applications where the environmental temperatures were as low as -269°C and as high as 400°C.

It can be easily fabricated by a wide variety of techniques, including die cutting, punching and thermoforming.

Polyimide film is available in 5 different thicknesses from 23 micron to 125 micron and in several different grades type HN being the most popular.

HN film can be laminated, metallized, punched, formed or adhesive coated.

Polyimide film is highly recommended for applications requiring an all-polyimide film with an excellent balance of properties over a wide range of temperatures.



Applications:

  • Mechanical parts
  • Electronic parts
  • Electrical insulation
  • Pressure sensitive tape
  • Fibre optics cable
  • Insulation blankets
  • Insulation tubing
  • Automotive diaphragms sensors and manifolds
  • Etching
  • Shims

TDS:
chemical resistant tape/yellow reflective tape/chemical resistant tape
Polyimide film Property Parameter Table
Item           TestingItem    Units                Standard value
1 Thickness mm0.025-0.05mm0.075-0.08mm0.100-0.125mm
2  Appearance——    Transparent or translucent gold films
3Densitykg/m31420±20
4 Tensile Strength  Mpa (MD)MPa≥135
(TD)MPa≥110
5Elongation ,%(MD)%≥35
(TD)%≥40
6Insulation Strength general averageMV/m≥150≥130≥110
individual≥100≥80≥70
7SurfaceResistivity/cm2Ω≥1.0×1013
8 volume ResistivityΩ.m≥1.0×1010
9Dielectric Constant  50Hz——3.5±0.4
10Temperature resistant
-40~300
11Dielectric dissipation factor  50Hz——≤1.0×10-3
12           shrinkage150℃%≤1.0
400℃









RFQ:





1. How to apply the samples?



Normally A4 size's samples are free of charge; for roll samples, you should bear the samples' cost and freight rate.



2.  What kind of trade style can you accept?



FOB, CIF, CIP, C&F,CFR



3.  Which circumstance should you pay us in advance, and the percentage?



Special specifications or large order amount; 30-50%.



4.  Are you factory or trading company?

A:We are the Manufactory specialized in polyimide tape polyimide film and masking tape 10years; Our factory have passed MSDS   SGS& ISO 9001& UL&RoHS certification



5.How long can I get to the samples?

 A:The samples will be ready for delivery within one week. The samples will be sent via express and arrive in 3-7days.





Company information:

Shenzhen Runsea Electronics Co., Ltd was founded in 2006,focused on special high temperature adhesive materials research and development, production and sales. Currently we have an independent development team, first-class production equipment and perfect sales mechanism. Through the tireless efforts of my colleagues, We own four advanced production lines, 2 automatic cut machines, and 15 practised workers. Automation operation,

trict quality control,best factory price,fast delivery,convenient transportation,and shipping service . Have more than 300 domestic and foreign enterprises to establish stable supply relationships. Including Samsung, BYD, Foxconn and

other large well-known companies. Reliable quality, prompt delivery, customer satisfaction is ourbiggest advantage. Welcome your advice and negotiate.
